سوئیچ اترنت صنعتی اچ ار یو ای HRUI HR500-SW10811GS

برای قیمت تماس بگیرید

سوئیچ 4 پورت اترنت 10/100Mbps
1 پورت Uplink اترنت گیگ
1 پورت Uplink SFP
سوئیچ اترنت صنعتی
48 ماه وارانتی بی قید و شرط (24 ماه گارانتی تعویض + 24 ماه گارانتی تعمیر)

Technical Parameter
Input/Output interface
Power	DC 12～55V
Ethernet	۸ 100M RJ45 Port1 Gigabit Uplink Ports ۱ Gigabit SFP Ports
Performance
Bandwitdth	۵.6Gbps
Package Forwarding Rate	۴.166Mpps
MAC Address	1K
Jumbo frame	۹.6Kbytes
Forwarding mode	Store and forward
MTBF	۱۰۰۰۰۰ 小时
Standard
Network Protocols	IEEE802.3IEEE802.3u IEEE802.3z
Industry Standard	EMI: FCC Part 15, CISPR (EN55022) class AEMS: EN61000-4-2 (ESD) EN61000-4-4 (EFT) EN61000-4-5 (Surge)
Network Media	10BASE-T: Cat5 or more UTP(≤۱۰۰ m)100BASE-TX: Cat5 or more UTP(≤۱۰۰ m) 1000BASE-TX: Cat5 or more UTP(≤۱۰۰ m)
Fiber Media	Multi-mode：850nm，1310nm. transmission distance：550m/2KmSingle-mode：1310nm，1550nm. transmission distance：۲۰/۴۰/۶۰/۸۰/۱۰۰/120Km
Certification
Safety Certificate	CE、FCC、RoHS
Environmental standards
Working Environment	Operating Temperature: -40～۷۵℃Storage Temperature: -40～۸۵℃ Humidity: 5%~95 %( non-condensing)
Physical Specifications
Specification Size	Product Size：۱۳۸×۱۰۸×۴۴ mmPacking Szie：۲۴۵×۱۹۰×60mm Product net weight: 0.567KG Product gross weight: 0.701 KG (excluding power supply)
Packing Info	Outer box size: 520×۳۲۰×400mmPacking quantity: 20 PCS Packing weight: 15.02KG
Voltage	Voltage input: DC12～55VPower wiring: 4 PIN industrial terminals (redundant V1+V1-, V2+V2-) / DC 2.1 (DC 2.1 cannot be used together with V1 and V2)
Packing List	۱. Industrial switch: 12. Instructions: 1PCS ۳. Qualification certificate, warranty card 1PCS ۴. Mounting ears: 1 pair
Function indication
LED Indicator	PWR, 1-8 Green, G10
PWR	Lighting：PoweredUn-Light：No Power
۱-۸ Green	Blinking slowly: 10/100 links are normalOff: link failure Flash: link data transfer
G10	Steady on: The optical fiber connection is normalNo light: no fiber connection Flash: link data transfer
DIP Funtion	V,G,E（Open Up, Close Down）
V	V：VLAN mode, ports 1-8 are isolated, and both communicate with ports 9 and 10
G	G：Normal mode
E	E：In extension mode, ports 1-8 are reduced to 10M and can be extended to 250 meters
